Sixia "Leask" Huang

I have a first-generation Apple Silicon MacBook Pro, one of the early M1 machines. I have been using Apple products for a long time, and I started testing the Apple Silicon transition before it was polished enough for normal people. I even spent time with the earlier A12-based Apple Silicon Mac mini Developer Transition Kit. So this is not a story about being surprised by a new architecture. I knew that the first generation would have rough edges. I expected firmware quirks, software gaps, and a different recovery model. What I did not expect was that a single USB-C port could quietly turn into the one physical point that decides whether an otherwise useful computer can be restored at all. The Port I Ignored Not long after I got the MacBook Pro, I noticed that one USB-C port did not work. It was the port on the left side, closest to the display hinge. The other ports worked. The machine charged. It ran normally. I had work to do, and this was not my only computer. So I did what many users do with a small hardware defect: I worked around it and moved on. Later, I upgraded and gave the M1 MacBook Pro to my son. It was still a good machine. For school work, browsing, and general daily use, it had more than enough life left in it. After another round of upgrades, I decided to prepare the machine for resale or trade-in. My usual process is simple: boot into recovery, erase the disk, install a clean system, and hand off a machine that is ready for the next owner. That workflow had been boring and reliable across years of Intel Macs. This time it was not boring. After erasing the system and rebooting, I learned the hard way that Apple Silicon Macs do not behave like the old x86 Macs in every recovery scenario. You cannot always treat them like machines that can be rescued with any random USB installer. When the firmware and recovery path require a revive or restore, Apple’s own process depends on another Mac running Apple Configurator, a data-capable USB-C cable, and a specific DFU port on the target machine. Apple documents this process clearly enough: to revive or restore an Apple Silicon Mac, the cable must be connected to the target Mac’s DFU port. Apple also documents the DFU port location by model. On many MacBook Pro models with Apple Silicon, that is the left-side USB-C port closest to the display hinge. In other words, the one port that had been dead on my machine was not just a broken port. In this failure mode, it was the recovery port. The Obvious Repair Was Not the Repair I have repaired enough computers to make an initial guess. A single dead USB-C port often suggests a failed I/O board, connector board, cable, or local damage around that path. I ordered the matching part from iFixit and replaced it. No change. The port still did not work, and the machine still could not be restored through the required path. At that point, the problem moved from a normal bench repair into Apple’s service system. I booked an Apple Store appointment and brought the MacBook Pro in. The staff ran through essentially the same checks I had already done. They confirmed the port failure and said it could be repaired as a paid service. I was not happy about paying. The port had failed long before I brought it in, and in my view the problem almost certainly existed while the machine was still within warranty. But I had not sent it in at the time. That part was on me. The quoted repair was expensive, but if it restored the machine, I was prepared to accept it. About a week later, Apple called back. Replacing the USB-C I/O board had not fixed the problem. The proposed repair was no longer the port board. It was the logic board, all related I/O boards, the battery, and effectively most of the lower half of the laptop. The price was roughly two thirds of what the computer had cost when new. That is the point where the repair stopped making sense. I was being asked to spend a large fraction of the original purchase price of a years-old laptop to fix one USB-C port. Add a bit more money and I could buy a newer machine in the same family. The economics were absurd, especially because the visible failure was so small. A Small Fault Became a Large Bill The deeper problem is not that hardware fails. Hardware always fails. Ports get damaged, connectors wear out, boards develop faults, and manufacturing defects sometimes take time to show themselves. The problem is the shape of the repair path. For years, Apple’s Mac service model has often felt less like repair and more like modular replacement at a very large scale. If the fault cannot be resolved by replacing one officially isolated part, the repair expands quickly. A tiny failure can become a logic board replacement. A port problem can become a major assembly replacement. A machine with plenty of useful life left can become economically irrational to fix. That is not just frustrating. It changes the real durability of the product. From the outside, this MacBook Pro looked repairable enough to save. The screen worked. The keyboard worked. The battery was usable. The Apple Silicon chip was still fast enough for years of ordinary use. The failure was local and boring: one USB-C path. But because that one path was also the firmware recovery path, and because Apple’s repair process escalated to replacing large assemblies, the machine became trapped between two bad choices: pay an unreasonable amount to repair an old laptop; abandon a computer that should still have years of useful life. That is bad product maintenance design. The DFU Port as a Design Weak Point There is also a specific technical lesson here. If a system has a required recovery path, that path should not depend on one easily damaged external connector with no practical fallback. A USB-C port is a mechanical part. It is exposed, frequently used, and easy to stress. Making one particular port the only viable route for low-level recovery creates a fragile single point of failure. The problem is not that DFU exists. DFU is useful. Firmware-level revive and restore workflows are necessary on modern secure systems. The problem is that the physical dependency is too narrow, and the repair path for that dependency is too expensive. A better design could have provided one of several escapes: allow any high-speed USB-C port to enter the recovery workflow; provide a more resilient internal service connector; make the recovery-related I/O path separately and affordably repairable; keep the official repair price proportional to the actual fault. None of those ideas are exotic. They are basic serviceability principles. Why This Matters Beyond One Laptop I am writing this because the story is larger than one unlucky MacBook Pro. Right-to-repair is not only about hobbyists wanting to open devices for fun. It is about whether a product can remain useful after one small part fails. It is about whether repair pricing reflects the actual failure, or whether the consumer is forced into replacing giant assemblies because the product was not designed to be maintained at human scale. This matters environmentally. A laptop that can be repaired and passed on is not e-waste. It can go to a student, a family member, a small office, a local community group, or someone who simply needs a reliable computer and cannot justify buying the newest model. It also matters economically. Not every useful computer needs to be a new computer. Not every child who needs a laptop for school needs the latest machine. A working M1 MacBook Pro is still powerful enough for many people. But that value disappears quickly when a tiny failure is priced like a major rebuild. And it matters ethically. If manufacturers design devices that are thin, sealed, glued, tightly integrated, and expensive to service, then repair stops being a realistic option for most people. The burden is pushed onto consumers and, eventually, onto the waste stream. I understand why modern devices are integrated. I understand the engineering trade-offs behind thin enclosures, compact boards, secure boot chains, and highly optimized internal layouts. I am not asking for laptops to return to the 1990s. But there is a line between integration and disposability. In this case, Apple crossed that line for me. A single failed USB-C port should not be able to turn a still-useful laptop into a nearly uneconomical repair. And a recovery process should not depend on a fragile external port with no affordable way out. This MacBook Pro did not fail because it was obsolete. It failed because the maintenance design around it was too brittle. That is the part that needs to change.

Since Codex has recently become the most important tool in my work, without question, keeping an eye on token usage at all times has become crucial. Today, I spent a little time vibe coding a Stream Deck plugin called Token Deck. It can display AI provider quotas, token usage, and Mac hardware status on Stream Deck. The project is open source on GitHub at leask/token-deck. Token Deck is a Stream Deck plugin for showing AI provider quota, token usage, and Mac hardware status on Stream Deck keys. The token action is powered by CodexBar, the hardware actions read local macOS status directly. Requirements macOS with Elgato Stream Deck 7.1 or newer. Node.js 24 or newer. CodexBar installed and configured. By default, the plugin uses CLI mode and runs a short-lived CodexBar command at each refresh: codexbar usage --provider codex --format json --json-only HTTP mode reads an explicitly running CodexBar JSON service: codexbar serve --port 8080 --refresh-interval 60 The plugin never switches data sources automatically. Pick CLI or HTTP in the action settings. Custom connection fields are optional. If CLI Path is empty, Token Deck checks the common Homebrew paths and then runs codexbar from PATH. If HTTP Endpoint is empty, Token Deck builds http://127.0.0.1:<port>/usage from the HTTP Port setting. Architecture Stream Deck runtime: Node.js/TypeScript via @elgato/streamdeck. Token usage source: explicit CLI or HTTP; there is no hidden fallback between data source modes. Hardware sources: macOS system commands and Apple SMC readings, kept independent from CodexBar. Rendering: each action generates a compact SVG image and sends it to the key with setImage. Refresh: every key refreshes on its timer and immediately when pressed. Development npm install npm run build npm run watch The official Stream Deck CLI linked the plugin into: ~/Library/Application Support/com.elgato.StreamDeck/Plugins/com.leask.token-deck.sdPlugin The link points back to this checkout’s com.leask.token-deck.sdPlugin directory. Actions AI Token Usage renders: provider name remaining percentage for the primary quota window primary reset countdown secondary quota mini bar Pressing the key forces a refresh. Hardware status actions can be added as separate keys without changing the token key: CPU Status Memory Status Disk Status GPU Status Network Status Temperature Status Battery Status Power Status The hardware keys refresh automatically and also refresh immediately when pressed. CPU Status samples aggregate CPU activity over a short interval. Memory Status shows current used memory based on Node’s OS memory counters. Disk Status aggregates mounted local physical storage and skips network mounts, Time Machine local snapshots, and disk images. On macOS APFS volumes are deduplicated by container, so the internal Data volume and an external USB disk array are counted once each instead of counting every APFS system volume. GPU Status reads Apple Silicon GPU utilization from IOAccelerator when that counter is exposed by macOS. Network Status samples local interface counters and shows combined download and upload throughput. Loopback, bridge, AWDL, and other virtual interfaces are ignored. Temperature Status uses Apple SMC temperature readings when available. If the native sensor module cannot be loaded in the Stream Deck runtime, it falls back to macOS thermal pressure from pmset -g therm instead of showing an error. Battery Status uses pmset -g batt on macOS. It shows internal battery level on laptops, UPS charge on desktop Macs with a supported UPS, and AC/no battery when no battery source is present. Power Status reads Apple SMC power keys without requiring sudo. If SMC power is unavailable, it falls back to Apple power telemetry from ioreg, then to voltage/current-derived power on systems that expose battery amperage. Validation Use these checks before shipping a local change: npx tsc --noEmit npm run build streamdeck validate com.leask.token-deck.sdPlugin streamdeck restart com.leask.token-deck Runtime logs are written under: com.leask.token-deck.sdPlugin/logs/com.leask.token-deck.0.log

Telegraf is one of the important community projects in the Telegram bot ecosystem. It has been around for years, it has a clean programming model, and many Node.js bots still depend on it. But the Telegram platform has not stood still. The official Bot API has kept moving, while Telegraf’s mainline updates have slowed down. That gap matters more now than it did a few years ago. Telegram is no longer only a place for simple command bots. It is increasingly a practical interface for AI agents: private chats, group coordination, media input, inline workflows, web app handoffs, notifications, and long-running assistant loops. If a framework does not keep up with the upstream API, every serious bot starts paying the tax locally. Developers patch missing methods, copy new Telegram types into application code, work around outdated examples, or avoid newer features entirely. That is not a good base for agent systems, and it is not a good outcome for a project as widely used as Telegraf. So I forked the project and started a larger modernization pass toward v6. The main pull request is telegraf/telegraf#2092. The companion type-definition work is telegraf/types#14. The docs follow-up is feathers-studio/telegraf-docs#23. What v6 is trying to do This is not a rewrite for the sake of rewriting. Telegraf’s existing model is still good: middleware, context helpers, Composer routing, scenes, sessions, and the low-friction bot.command / bot.on style are all worth preserving. The goal of v6 is to make that model current again: align Telegraf with Telegram Bot API 9.6; expose runtime wrappers for the official API surface; use @telegraf/types as the source of truth for future Bot API syncs; modernize the runtime baseline around Node.js 20 and native platform APIs; remove stale compatibility assumptions that made the networking layer harder to maintain; add tests that make future API drift visible instead of silent. The most important design choice is to keep future Bot API updates mechanical. The type package should describe Telegram’s canonical API. Telegraf should then wrap every typed method it can support, and tests should fail when the runtime falls behind the declarations. That turns “someone should check the changelog” into a concrete maintenance workflow. Catching up with the Bot API The v6 branch updates Telegraf for the current Bot API generation and adds coverage around the newly typed surface. The tests now inspect @telegraf/types and verify that Telegram has wrappers for the official methods. This is a small but useful guardrail: once the type package moves, the runtime can no longer quietly miss a method. Newer request shapes also exposed a multipart edge case. Some Bot API payloads can contain nested InputFile values, so the upload serializer now handles those recursively. That is the kind of detail that tends to break only after a real bot starts using a new Telegram feature. It is better to cover it in the framework. The types work is currently staged through the companion PR. Until it lands upstream or is published as an official package, the Telegraf PR temporarily points at my @telegraf/types fork. That is not the final desired dependency; it is only a way to validate the runtime against the actual Bot API 9.6 shape while the upstream review is happening. Modern Node, less baggage The networking layer changed more than I first expected. Older Telegraf releases depended on node-fetch and exposed node-fetch-specific agent options such as telegram.agent and telegram.attachmentAgent. That made sense in older Node versions, but it is no longer the right default for a modern Node.js runtime. Telegraf v6 uses the native globalThis.fetch by default. It no longer bundles node-fetch, and the old agent hooks are replaced by a more general extension point: inject your own telegram.fetch. The important part is not the specific fetch implementation. Users can still bring the networking behavior they need for proxies, custom TLS, compression, logging, or special deployment environments. Telegraf just needs one clean hook, and that same hook is used for both Bot API calls and URL attachments. The Node.js baseline also moved to Node 20. That allowed the codebase to remove older runtime shims and update supporting tools such as the timeout path, lint configuration, tests, and release workflow. A major version is the right place to do that. Keeping a modern framework tied to old platform assumptions makes every future change more expensive. Tests as a maintenance contract The branch is not only a pile of wrappers. I spent a lot of time making the tests describe the intended maintenance contract: Bot API methods declared by @telegraf/types must be represented at runtime; newer Bot API fields should be visible in the generated type surface; custom fetch must work for normal API calls; custom fetch must also work for URL attachments; request timeout behavior must abort fetch calls cleanly; multipart form data must preserve nested InputFile payloads; webhook rejection behavior must return useful HTTP status codes and headers. The current Telegraf test suite passes with 180 tests. The package also builds, lints, generates TypeDoc output, and passes an npm pack dry run. There are still TypeDoc warnings, but they are warnings in the generated reference surface, not failing runtime behavior. The documentation had to move too Modernizing the code without updating the docs would leave users with the old mental model. That is why I also opened a documentation PR against feathers-studio/telegraf-docs. The docs update does a few practical things: explains the new native globalThis.fetch default; replaces old proxy examples based on telegram.agent with telegram.fetch; updates the context options shape to include fetch and requestTimeout; refreshes examples that were stale against newer Bot API typings, such as thumbnail_url, correct_option_ids, and telegraf/types imports; fixes framework-specific webhook examples for Fastify and Koa; moves the AWS Lambda example to the Node.js 20 runtime. I did not open a separate PR against the upstream gh-pages branch. That branch contains generated TypeDoc output for the published site. The right path is to land the source changes, then let the release workflow regenerate the site from the upstream repository when v6 is tagged. Manually editing generated HTML would create a large diff with very little review value. Why this matters now Telegram is a surprisingly good surface for AI systems. It already has identity, contacts, groups, rich media, push notifications, inline interactions, and mobile clients that people actually use. For agents, that makes Telegram a natural place to receive instructions, ask follow-up questions, send files, and coordinate with humans. But agent-facing infrastructure needs boring reliability. Missing API coverage, stale types, and outdated networking assumptions are exactly the small cracks that become annoying in production. A framework like Telegraf should make the common path simple while still giving advanced users room to customize the edge cases. That is the v6 direction: keep the Telegraf programming model, catch up with Telegram’s official API, modernize the runtime, and make future API updates less heroic. Current status At the time of writing: the main Telegraf v6 PR is open as telegraf/telegraf#2092; the Bot API 9.6 types PR is open as telegraf/types#14; the documentation PR is ready for review as feathers-studio/telegraf-docs#23. The work is intentionally staged. First the official type surface needs to be accepted or published. Then the main Telegraf dependency can switch back from the temporary fork to the official @telegraf/types release. After that, the docs can point at the published telegraf@^6.0.0 package instead of the stacked branch. That is a bit of coordination, but it is the kind that makes an open source upgrade reviewable. Types, runtime, tests, release notes, and examples each have their own place, and the final result should be a Telegraf line that is much easier to keep current with Telegram from here.

Tab(ter)minal, the Cloud-Native, Proactive AI Integrated Terminal works in modern browsers. Seamlessly code from your desktop, tablet, or phone with an intelligent, persistent, and rich experience. This project was built using Gemini and Codex wich 80% vibe-coding, means built for the vibe, with the vibe. 🌟 Why Tabminal? Tabminal bridges the gap between traditional CLI tools and modern AI capabilities, all while solving the UX challenges of coding on desktop and mobile devices. As a long-time terminal user who frequently needs to step away from my computer while maintaining my workflow, and considering the various scalability issues of traditional terminals alongside the irreversible trend of vibe-coding, I reconsidered a solution that would first serve my own needs. Then, it would serve others whose workflows happen to be similar to mine. So, while waiting for AI to write code for the company, I tried to vibe a terminal from scratch that could meet my daily work needs and that I would enjoy using. As a result, I intermittently wrote this project. I believe this project is not for everyone. However, it is especially suitable for CLI and AI enthusiasts, which is the core motivation behind this project’s creation. ✨ Innovative Designs Server-side session persistence ensures your sessions with the AI agent are maintained, allowing you to pick up where you left off at any time. Fast and stable connection management delivers a seamless, agile experience across platforms and devices, with native support for network roaming. Enjoy a comprehensive Progressive Web App (PWA) experience anytime, anywhere; all you need is a modern browser to start working. Proactive AI integration means your terminal becomes your work context. You can ask questions about your current session at any time, and the AI will automatically retrieve the context to accurately solve problems, even proactively offering assistance when commands fail. Cloud-native design enables access via Zero Trust or VPN, providing unprecedented convenience for managing cloud servers. 🧠 AI-Native Intelligence Powered by modern AI models (via OpenRouter), Tabminal understands your context. (Defaults to Gemini 2.5 Flash for optimal speed/performance balance if not configured) Context-Aware Chat: Type # how do I… to ask questions. The AI knows your CWD, Environment, and Recent History. Auto-Fix: Command failed? Tabminal automatically analyzes the exit code and error output to suggest fixes. No copy-pasting required. Web Search: Enable Google Search integration to let the AI fetch real-time answers from the web. 📱 Ultimate Mobile Experience Built from the ground up for iPadOS and iOS. HHKB Virtual Keyboard: You can perform nearly all terminal operations on any device, without being frustrated by os limitations. Responsive Layout: Auto-adapts to landscape/portrait modes, respecting Safe Areas and Notches. PWA Ready: Install to Home Screen for a full-screen, native app feel. 💻 Powerful Desktop Features Persistent Sessions: Your terminal state lives on the server. Refresh or switch devices without losing your work. Built-in Editor: Integrated Monaco Editor (VS Code core) allows you to edit files directly on the server. Visual File Manager: Sidebar file tree for easy navigation. Network Heartbeat: Real-time latency visualization. 🚧 Github Repo: GitHub - Leask/Tabminal

A New Way to Build a Dashboard (for geek only). GitHub - Leask/Dream-Dashboard: Terminal dashboard for real-time UniFi gateway throughput, latency, infrastructure inventory, and client act My work relies heavily on my homelab environment, which I’ve described in detail in a previous article, available here. In practice, I need to stay informed about the status of my cluster, including storage services, disk health, CPU/GPU/memory load, and network I/O. I’ve been exploring how to create a dashboard that provides a comprehensive overview of all this information. As a CLI enthusiast, I prefer command-line solutions over GUIs whenever possible. After some consideration, I decided to use tmux’s multi-pane feature as the foundation for my dashboard. By combining tmux with appropriate scripts, I can monitor the various operating states of my servers. Therefore, I integrated btop, ceph, mdadm, nvtop, asitop, and a tool I developed to monitor my UniFi gateway into a single tmux startup script. This script also includes simple features such as automatically restarting panels if they encounter errors. The result is a readily available and simple dashboard. Currently, it displays the basic status of my four core computing nodes, Ceph health and metrics, the status of each mdadm array, the health of all local disks, the top active graphics cards, and the status of my network egress. You can easily create your own version, writing a bash script for this is simple, or you could ask AI to help you piece it together. However, that’s not the main point. The fun part is that I sometimes need to check on my home machines while I’m away, and I even wanted to configure my primary workstation’s screen saver to display this dashboard. So, my next step was to turn the dashboard into a web service, accessible through a web browser. This also makes it easier to migrate to other uses and more convenient to showcase. Thus, this project was born. The code is simple, most of it was generated by prompting AI, and it hasn’t been thoroughly organized. Feel free to adjust it to suit your environment and needs. I then exposed the service through Cloudflare’s Zero Trust tunnel to authorized users, and it was basically done. Oh, I mentioned screen savers. I found that the easiest way to set a webpage as a screen saver on macOS is using the webviewscreensaver project. However, it has some issues, such as misaligned webpage rendering on macOS 26. Therefore, I had to fork it and ask Codex to fix the most critical bugs. You can build directly from my branch if needed.

故事從去年開始，因為越來越多的數據存儲和 AI 計算需求，我開始重新組織家裏的計算資源，把零散的計算資源整合成更便於管理和維護的統一資源架構。陸陸續續折騰了一段時間，在這個過程中，我遇到了很多的問題，之前也在 X 上也和大家分享過一些，大家建議我都寫下來，經過一些考慮，我決定成體系地介紹一下如何一步一步搭建適合家庭網絡規模的高可用超融合數據中心。 當然了，說數據中心是一個誇大的概念，但是這個過程的確已經覆蓋了搭建一個小型數據中心所需要的常見類別的設備和比較完整的步驟。本文會有一些設備選型上的考慮，也會有很多配置上的細節，不一定很有含金量，但求給大家一些參考。事實上，玩homelab並非一定要很 fancy 的硬件，設備選擇上豐儉由人，通過合理的配置和組合，只要樂意折騰，都可以學到很多，並且組合出適合自己的工作環境。以自己經驗為例，我在東拼西湊的設備上調校出來的集群，已經穩定為幾個網站提供了一年多的穩定服務，在包括 AI 計算，矢量數據索引等工作上更是已經處理過超過 100T 的吞吐，運行相當穩定和高效。我將會從網絡搭建開始，講到存儲，再到虛擬化，因為我覺得考慮 homelab 的配置，應該遵循這一個順序，避免來回折騰，浪費時間。 什麼是超融合 關於數據中心如何從傳統架構演進到融合架構再到超融合架構，可以簡單過一下這個視頻。簡單來說，在傳統的數據中心，服務器節點一般分為三大類別，網絡服務器，存儲服務器，應用服務器： 網絡服務器包括光電線路的路由器，防火牆，交換機，IoT 網關等等； 存儲服務器往往以集群的方式存在，對應用服務器提供冷熱數據的訪問，二進制數據和結構化數據的存儲、備份等等，有多方式實施，如 NAS，SAN，DAS 等型態； 應用服務器承擔著要的計算任務，包括 CPU 為主的運算以及新興的 GPU 為主的運算，提供的服務包括 Web 服務，郵件服務，虛擬機，容器集群，密集計算服務等等。 超融合HCI (Hyper-Converged Infrastructure)的概念比較新，它是隨著虛擬化的發展而提出來的一重新組織服務器資源的策略，也是所謂軟件定義數據中心的核心概念之一。超融合數據中心將網絡（部分），存儲，運算三種資源融合在一起，形成一個統一的資源池，完全由虛擬化平台提供各種計算和存儲資源。 在一個超融合計算中心裡面，除了物理主機的網絡連接需要單獨的網絡設備之外，其他的資源都可以通過虛擬化平台來提供，每個物理主機都是全能節點，承擔部分的計算和存儲，他們之間緊密相連，資源共享，相互備援。超融合不是一個特定的單一軟件技術，它其實脫胎於虛擬化、分佈式存儲等一系列技術上的概念。在實施上，常見的超融技術棧有 PVE (Proxmox VE) + Ceph, VMware vSphere, Hyper-V + S2D 等等。本文以 PVE + Ceph 為例子，其他方案的包裝可能有差異，但是原理是相通的。 從機櫃開始 接下來我會介紹一些我選用的硬件，沒有任何廣告的成分，因為 X 上很多人對我用的設備感興趣，這裡簡單介紹一下一些基礎的選型思路。 首先要有一個機櫃。選型上，除了通風設計的考慮之外，我認為首先要測量一下計畫存放的房間或者地下室的高度，在能容納的高度範圍內選擇一個最高的。高度決定了這套設備將來的擴展性，不要猶豫，越高越好。我的地下室有一根懸梁，限制了最大高度，所以只能選擇的最大 32U 的，具體是這款：StarTech.com 4-Post 32U Server Rack Cabinet。 下面這個表列出了多少 Unit 的櫃子大概有多少高度，範圍從 1U 到 48U，也可以直接在這個頁面上動態估算。 Rack Units Height (in) Height (ft) Height (cm) 1U 1.75″ 0.15′ 4.4 cm 2U 3.5″ 0.29′ 8.9 cm 3U 5.25″ 0.44′ 13.3 cm 4U 7″ 0.58′ 17.8 cm 5U 8.75″ 0.73′ 22.2 cm 6U 10.5″ 0.88′ 26.7 cm 7U 12.25″ 1.02′ 31.1 cm 8U 14″ 1.17′ 35.6 cm 9U 15.75″ 1.31′ 40 cm 10U 17.5″ 1.46′ 44.5 cm 11U 19.25″ 1.6′ 48.9 cm 12U 21″ 1.75′ 53.3 cm 13U 22.75″ 1.9′ 57.8 cm 14U 24.5″ 2.04′ 62.2 cm 15U 26.25″ 2.19′ 66.7 cm 16U 28″ 2.33′ 71.1 cm 17U 29.75″ 2.48′ 75.6 cm 18U 31.5″ 2.63′ 80 cm 19U 33.25″ 2.77′ 84.5 cm 20U 35″ 2.92′ 88.9 cm 21U 36.75″ 3.06′ 93.3 cm 22U 38.5″ 3.21′ 97.8 cm 23U 40.25″ 3.35′ 102.2 cm 24U 42″ 3.5′ 106.7 cm 25U 43.75″ 3.65′ 111.1 cm 26U 45.5″ 3.79′ 115.6 cm 27U 47.25″ 3.94′ 120 cm 28U 49″ 4.08′ 124.5 cm 29U 50.75″ 4.23′ 128.9 cm 30U 52.5″ 4.38′ 133.4 cm 31U 54.25″ 4.52′ 137.8 cm 32U 56″ 4.67′ 142.2 cm 33U 57.75″ 4.81′ 146.7 cm 34U 59.5″ 4.96′ 151.1 cm 35U 61.25″ 5.1′ 155.6 cm 36U 63″ 5.25′ 160 cm 37U 64.75″ 5.4′ 164.5 cm 38U 66.5″ 5.54′ 168.9 cm 39U 68.25″ 5.69′ 173.4 cm 40U 70″ 5.83′ 177.8 cm 41U 71.75″ 5.98′ 182.2 cm 42U 73.5″ 6.13′ 186.7 cm 43U 75.25″ 6.27′ 191.1 cm 44U 77″ 6.42′ 195.6 cm 45U 78.75″ 6.56′ 200 cm 46U 80.5″ 6.71′ 204.5 cm 47U 82.25″ 6.85′ 208.9 cm 48U 84″ 7′ 213.4 cm 需要注意的是，櫃子會有上蓋和底座，有一些底座下面還有輪子，所以一定要根據自己的實際需求來選擇，並且多做幾次測量避免尷尬，因為要退換的話，將會非常麻煩，一個比較正式的幾架，是相當重的。 機器上架 我們接下來會挑選一些設備，從網絡設備出發，但是對於後面各種類型的設備在插入機櫃之前，都需要大致考慮好機器的擺放順序，所以我們先簡單了解一下上架機器的一些基本準則： 重的機器往下放，主要是存儲和 UPS 等； 輕的機器往上放，主要是電源管理，網絡設備，輔助設備，KVM 等； 太熱的機器不要放在一起，要有間隔，盡可能讓熱的機器靠近風扇防止機機積熱； 根據自己的身高和維護習慣安排 KVM 的位置，大概率可能會被安排在機櫃的中上部分； 盡可能多安排風扇，保持通風，可以大大減少機器因為積熱帶來的穩定性問題，風道設計上，應該從下往上，從前往後，比較細緻的可以上自動控溫設備。 這裡引用一個比較理想情況下的單櫃排列策略圖： 🔔 需要注意，其實每個櫃子的實際情況都是不一樣的，非一體化設計的機櫃單元，很多時候會因為線纜長度的制約，走線的需要，機器的尺寸、重量，甚至個人的喜好而有所調整，這都很常見，事實上隨著業務的變化，我也調整過幾次才達到滿意的效果。 網絡規劃 網絡設備的選擇上，首先要考慮的是速率上的規劃。我建議所有用戶，都從 10GE 開始考慮，低於 10GE 的設備，強烈不建議購買了。有條件的話，40GE 或者 100GE 都可以考慮。 另一點就是考慮傳統 RJ45 電口還是 SFP/SFP+/SFP28/QSFP+/QSFP28 等光模塊接口。在這個問題上，我考慮了很久，主要的原因是，我已經有一部分的設備已經是 10GE 電接口的，如果我選擇 SFP+ 路線，我將無法兼容已有的設備。但是 10G 以上電口在我之前的使用中，的確遇到一些問題，網卡載荷大，發熱高，我的確想趁機會演進到光口路線。在花了很多時間考量，最後決定都要有，事實上到目前為止，我依然覺得這是一個正確的決定，目前的網絡容量和靈活性讓我在工作中獲得了很大的彈性，並預留了足夠的性能空間。 我選用的設備 聚合交換機 UniFi USW-Pro-Aggregation 正如我前面說的，我需要有足夠的電口和光口，可管理，可堆疊，可擴展，高性能，穩定可靠的交換機作為核心網的基礎。這款交換機有 32 個 28 個 10G SFP+ 接口和 4 個 25G SFP28 接口，交換容量是 760Gbps，非阻塞 IO 能到 380 Gbps，支持 VLANs 和鏈路聚合，Layer 3 和 Layer 2 都是可管理的。 以太網交換機UniFi USW-EnterpriseXG-24 我使用這一款交換機來兼容原有的設備，支持 Wi-Fi 熱點、遠程 KVM、智能家居等傳統電口網絡設備。它有 24 個 10G RJ45 電口和 2 個 25G SFP28 光口，交換容量是 580Gbps，非阻塞 IO 能到 290Gbps，同樣支持 VLANs， Layer 3 和 Layer 2 可管理。 入口路由/防火牆 UniFi Dream Machine Special Edition (UDM-SE 180W) 這款設備有一個 10G SFP+ Uplink 作為主要入口，一個 2.5G RJ45 Uplink 作為備用網絡入口，有 1 個 10G SFP+ Downlink 和 8 個 GE RJ45 Downlink，其中 2 個電口支持 PoE+， 其餘 6 個是電口都支持 PoE。它唯一讓我不滿意的是 Uplink 只開放了 3.5Gbps，雖然我只有 3Gbps 對等光線接入，的確已經足夠，但是總覺得餘量不足，比較懊悔的是，我下單不久Dream Machine Pro Max (UDM-Pro-Max) 就上市了，它的 Uplink 能到 5 Gbps，就好不少。 主要網絡設備的拓撲 +-----------------------------------------------------------------+ | INTERNET | +-----------------------------------------------------------------+ | | | +----------------+ +------------------+ +-------------------------+ | Bell Fibe (3G) | | Starlink (Bak 1) | | Nighthawk M5 5G (Bak 2) | +----------------+ +------------------+ +-------------------------+ | | | 10G 2.5G 1G | | | +-----------------------------------------------------------------+ | Dream Machine Special Edition | +-----------------------------------------------------------------+ | 10G SFP+ | +-----------------------------------------------------------------+ | USW-Pro-Aggregation | +-----------------------------------------------------------------+ | 50G LACP (25G SFP28 * 2) | +-----------------------------------------------------------------+ | USW-EnterpriseXG-24 | +-----------------------------------------------------------------+ 存儲規劃 在網絡安排好之後，我建議先考慮存儲，存儲決定了這套設備能處理的數據的極限，這可能包括你工作需要存儲的數據，例如視頻工作者，AI 工程師等等往往都對存儲空間有較高的需求。對於 homelab 來說，可能還有媒體服務，遊戲串流服務，相冊服務等等一些個人數據的存放。 坦白說，在有條件的情況下，盡可能多安排存儲，會少走很多彎路。存儲池我個人建議至少安排一個 SSD 高速池用來支持虛擬化、數據庫、AI 運算等，加一個 HDD 大容量存儲池，用來存儲備份數據，非活躍項目的大體積數據等。我個人推薦存儲方案的選擇應該滿足兩個條件：穩定是大前提，靈活可伸縮相當重要，我最終的方案是： 高速存儲池通過 Ceph 實現，SSD + NVME，單盤 4TB * 5 盤 * 4 節點； 大容量存儲池通過 Mdadm RAID6 實現，HDD，單盤 18T * 12 盤； 其中的 Ceph 是超融合重要的一環，後面會詳細解釋。至於大容量的存儲池為什麼選擇 Mdadm 而不是 ZFS 或者 LVM，這個主要看個人的喜好。我對穩定性和靈活性都有很高的要求，ZFS 的確很強大，但是對於陣列的伸縮性比較侷限，不能滿足我喜歡折騰的喜好。LVM 對快照的支持比較差，而且還有不少其他問題尚未解決，例如內建 RAID 的可恢復性等等。所以我還是選擇了在 Linux 上廣泛使用，穩定性同樣無可挑剔的 Mdadm，並在上面使用 Btrfs 文件系統來支持快照和文件校驗，有意思的是，這個組合恰好是 Unifi UNAS Pro 所使用的方式。當然，這個主要看個人喜好，對擴展性，靈活性，穩定性，容災重建等每個人的理解都不一樣，選擇自己喜歡的，不要陷入神仙打架的局面。 Ceph 重點介紹一下 Ceph，這是開源超融合方案的核心組件，如果你搭配 PVE 使用的話，選擇 Ceph 作為存儲池，可以獲得非常好的性能，擴展性和穩定性，同時 PVE 面板上整合的 Ceph 管理工具簡單實用，可以快速管理存儲集群的健康狀態。當然 PVE 對 Ceph 的集成雖然很好，但是 Ceph 是一套十分強大和複雜的分佈式存儲系統，很多高級操作依然需要命令行，這個無可避免，後面我會介紹一些比較常用的命令。 為什麼說 Ceph 是超融合方案的核心？其實前文已經提到，在超融合數據中心裡面，所有的資源是充分共享和網絡化的。你可以理解，業務不是運行在單一機器，或者單一個虛擬機裡，粗略又抽象地理解，服務是跑在集群上。整個集群一起來支撐每個業務，機器之間緊密相連，相互備援。在 PVE 中正確配置 Ceph 作為存儲後端之後，虛擬機是可以在集群裡面隨意遷移的，VM 可以不關機從一個主機直接遷移到另一個主機上運行，對外甚至是無感知的。這帶來了很多便利，例如一台機器故障或者需要維護重啟，你完全不用擔心上面的業務，PVE 可以自動把運行中的 VM 在線遷移到集群中其他機器上運行。這種無縫遷移依賴集群把存儲視為一個整體，從不同機器都可以訪問到一樣的數據。PVE 當然也支持通過 SAN 網絡或者 NFS 等傳統方案來實現統一存儲，但顯然 Ceph 是更面向未來的選擇。 有幾點需要注意： 為了獲得足夠理想的 IOPS 性能，至少一個全 SSD/NVME 存儲池是值得優先考慮的； 為了獲得足夠的冗余，推薦從 4 個節點起步，size 4，min 2 應該是最低安全保障，這相當於集群中每份數據保存在 4 個節點上，至少滿足 2 個節點在線時允許讀寫，2 個節點離線不影響業務。 安裝虛擬化平台 PVE Proxmax VE 基於 Debian，這其實也是我選擇它的原因之一。作為多年 Debian 用戶，我對於它的穩定性相當有信心。它唯一缺點是保守，stable 分支軟件包相對較舊，需要嘗新可以用其他分支，但是我認為宿主機的穩定性是最重要的，嘗新完全可以在 VM 中折騰。 事實上我推薦的安裝方式並不是直安裝 PVE，而是先安裝 Debian，然後安裝 PVE 軟件包。這個主要的原因在於，我在幾個服務器上，嘗試直接安裝 PVE 都失敗，可能是我環境的問題，也有其他朋友和我遇到相似的問題，這裡不深究，但是從 Debian 上安裝，表現更符合預期： 使用引導介質直接安裝 PVE; 從 Debian 安裝 PVE PVE 官方文檔要求 Debian 版本為 12(Bookworm)，事實上大家可以放心直接在 stable 分支上運行。有一些包比 PVE 預設的更新，但是沒有任何兼容性問題。 簡述安裝步驟 1. 安裝 Debian 12 Bookworm，切換到 stable 分支 2. 在 /etc/host 中加入當前主機的 IP 地址 # vim /etc/host [本機本地 IP] [當前主機名] Example: 192.168.1.64 Enlightenment 確保地址正確 $ hostname --ip-address 確保返回的地址是 /etc/host 中配置的地址，而不是 127.0.0.1 或 ::1 等 loopback 地址。 3. 添加 PVE 的 apt 源 # echo "deb [arch=amd64] http://download.proxmox.com/debian/pve bookworm pve-no-subscription" > /etc/apt/sources.list.d/pve-install-repo.list 4. 添加 PVE 源的密鑰 # wget https://enterprise.proxmox.com/debian/proxmox-release-bookworm.gpg -O /etc/apt/trusted.gpg.d/proxmox-release-bookworm.gpg 驗證密鑰（最新密鑰 hash 值請參考官方文檔）： $ sha512sum /etc/apt/trusted.gpg.d/proxmox-release-bookworm.gpg 7da6fe34168adc6e479327ba517796d4702fa2f8b4f0a9833f5ea6e6b48f6507a6da403a274fe201595edc86a84463d50383d07f64bdde2e3658108db7d6dc87 /etc/apt/trusted.gpg.d/proxmox-release-bookworm.gpg 5. 更新 apt 源，升級系統 # apt update && apt upgrade -y 6. 安裝 PVE 內核 # apt install proxmox-default-kernel # systemctl reboot 7. 安裝 PVE 套件 # apt install proxmox-ve postfix open-iscsi chrony 8. 刪除 Debian 默認內核 # apt remove linux-image-amd64 'linux-image-6.1*' # update-grub 9. 刪除 os-prober 避免虛擬機被錯誤加到引導菜單。 # apt remove os-prober 10. 刪除企業版 apt 源，僅使用開源版組件 如果你打算購買企業版，忽略此步驟。 # rm /etc/apt/sources.list.d/pve-install-repo.list 11. 重啟，確保可以正常引導 如果你的 Debian 是啟動到命令行的，你應該會看到 PVE 的歡迎介面，如果你是啟動到圖形介面的，你不會看到任何變化，可以執行以下命令查看 PVE 是不是已經正確安裝： $ pveversion 如果看到類似以下的輸出，說明 PVE 已經正確安裝： pve-manager/8.3.3/f157a38b211595d6 (running kernel: 6.11.0-1-pve) 注意，如果無法看到 PVE 歡迎介面，先檢查一下上面 IP 地址的步驟。 12. 訪問 PVE 管理面板 PVE 管理頁面默認可以通過這個地址訪問： https://[節點本地 IP 地址]:8006 例如： https://192.168.1.64:8006 注意協議是https，瀏覽器需要忽略一下自簽證書的安全檢查。管理頁面默認可以通過系統的root帳戶密碼登陸，Realm選擇Linux PAM standard authentication，進入系統之後配置其他登錄驗證方式。 至此 PVE 節點已經完成了基本的安裝，下面我會開始介紹一些必須的配置項目。 配置網絡 你需要先配置一個網橋，便於 VM 訪問網絡，PVE 官方文檔中有詳情： 1. 先查詢網卡設備號 $ ifconfig -a 識別出網口設備號，如 eno1, enp1s0 等等，紀錄下來。 2. 配置網橋 編輯 /etc/network/interfaces 文件，根據需要添加以下內容： auto lo iface lo inet loopback auto [網口設備號] iface [網口設備號] manual auto [新建網橋設備號，如 vmbr0] iface [新建網橋設備號，如 vmbr0] inet static address [配置為安裝步驟中指定的 IP 地址]/24(可通過`/`配置網段，也可通過`netmask`來配置) netmask [子網掩碼](如果上面一行已配置網段，此處可忽略) gateway [配置網關地址] bridge-ports [網口設備號，如前所述] bridge-stp off bridge-fd 0 3. 配置鏈路聚合 如交換機支持 LACP，或有兩個以上交換機且同時連接，強烈建議配置鏈路聚合，你可以聚合兩個或多個網絡接口，這樣可以提高網絡的穩定性和帶寬，對集群的穩定性，特別是 Ceph 的穩定性有很大的幫助。 編輯 /etc/network/interfaces 文件，根據需要添加以下內容，注意由於增加了鏈路聚合層，網橋中指定的設備號要物理網口設備號改為聚合設備號： auto [網口 1 設備號] iface [網口 1 設備號] manual auto [網口 2 設備號] iface [網口 2 設備號] manual [...] auto [新建鏈路聚合設備號，如 bond0] iface [新建鏈路聚合設備號，如 bond0] inet manual bond-slaves [網口 1 設備號] [網口 2 設備號] [...] bond-mode 802.3ad bond-xmit-hash-policy encap3+4 bond-miimon 100 bond-downdelay 200 bond-updelay 200 bond-lacp-rate 1 auto [新建網橋設備號，如 vmbr0] iface [新建網橋設備號，如 vmbr0] inet static address [配置為安裝步驟中指定的 IP 地址]/24(可通過`/`配置網段，也可通過`netmask`來配置) netmask [子網掩碼](如果上面一行已配置網段，此處可忽略) gateway [配置網關地址] bridge-ports [聚合設備號，如 bond0，需和上一小節保持一致] bridge-stp off bridge-fd 0 4. 重啟網絡以應用配置 # systemctl restart networking 5. 開啟 Jumbo Frame Jumbo Frame 是 10GE 對於高速網絡至關重要，更大的包可以減少包的數量，降低 CPU 在封包和解包過程的負擔，顯著提升網絡的吞吐量。對於 Ceph 來說，Jumbo Frame 至關重要。 配置主要網絡設備的 MTU 為 9000，根據前面的配置填入合適的設備號，例如 vmbr0(無聚合) 或 bond0(有聚合)： # /usr/bin/ip link set [設備號] mtu 9000 你可把類似的配置放在/etc/network/interfaces中，也可直接把上面的命令放在/etc/crontab中，通過@reboot和sleep(等待網絡初始化完成)來執行，完全是個人喜好，此處不作贅述。 注意！請保證每個節點使用相同的 MTU 封包尺寸，這將是集群穩定性的關鍵，如果 MTU 不一致，PVE 集群會出現不穩定，節點掉線等情況。對於 Ceph 尤其如此，不一致的 MTU 會導致 OSD 心跳受阻，進而導致 OSD 頻繁從集群中離線。我有一個節點出現這個情況花了很長時間才解決。 6. 測速，確保速度符合預期 為了方便調試，我建議所有節點開啟 iperf3 服務，這樣可以大大方便節點間的的網絡調試。 # apt install iperf3 從 A 節點測試到 B 節點的網絡速度： # iperf3 -c [B 節點 IP 地址] -P [線程數] 其中-P參數可以指定測試的線程數，默認是 1 個線程。如果需要測試多個線程的話，例如測試 LACP 的效果，可以指定多個線程，例如-P 10表示使用 10 個線程進行測試。 配置顯卡直通 如有 AI 運算、遊戲或視頻剪輯需求，顯卡直通必不可少，這裡面網上有很多的介紹，有對有錯，這裡簡單總結一下步驟： 1. 確保BIOS中開啟IOMMU 確認 IOMMU 可用尤其重要，有一些主板是默認關閉的，也有一些主板是默認開啟的，需要手動確認一下： # dmesg | grep -e DMAR -e IOMMU 確保輸出中有： DMAR: IOMMU enabled 2. 確保IOMMU interrupt remapping可用 # dmesg | grep 'remapping' 確保輸出中有： AMD-Vi: Interrupt remapping enabled [OR] DMAR-IR: Enabled IRQ remapping in ******* mode 如找不到，可嘗試強制開啟： # echo "options vfio_iommu_type1 allow_unsafe_interrupts=1" > /etc/modprobe.d/iommu_unsafe_interrupts.conf 3. 編輯/etc/modules確保有以下的條目 vfio vfio_iommu_type1 vfio_pci vfio_virqfd 4. 如計畫虛擬macOS，確保ignore_msrs=1被正確配置 # echo "options kvm ignore_msrs=1" > /etc/modprobe.d/kvm.conf 5. 讓宿主機啟動的時，忽略部分顯卡驅動，預留資源給 VM 不加載 AMD 顯卡的驅動： # echo "blacklist amdgpu" >> /etc/modprobe.d/blacklist.conf # echo "blacklist radeon" >> /etc/modprobe.d/blacklist.conf 不加載 NVIDIA 顯卡的驅動： # echo "blacklist nouveau" >> /etc/modprobe.d/blacklist.conf # echo "blacklist nvidia*" >> /etc/modprobe.d/blacklist.conf 不加在 Intel 顯卡的驅動： # echo "blacklist i915" >> /etc/modprobe.d/blacklist.conf 6. 更新啟動鏡像 # update-initramfs -u 🔔 完成以上操作後，大部分 AMD、NVIDIA 和 Intel 顯卡都能直通給 VM 使用了，需要注意如宿主機需要 GUI，不要忽略 Intel 核顯，這樣可以保留板載顯卡用來亮機和調試。 如經歷上面操作後依然出現問題，個人建議更換支持度更高和更新的顯卡，雖然網上有很多 workaround 可一定程度解決問題，但穩定性和兼容性難以保證，同時需要額外的 hack 來解決的顯卡一般都較老，算力上意義不大，可趁機升級。更多信息可以參考官方文檔。 組建 PVE 集群 每一個 PVE 節點都要經歷上面的安裝和配置，在所有節點都完成配置後，就可以開始把 PVE 節點組合成集群。為了穩定可用，PVE 集群和 Ceph 集群都需要最少 3 個節點。個人推薦最少 4 個節點起步。兩個節點，當其中一個節點 down 掉之後，投票無法過半數，需要手動修改投票規則才能啟動虛擬機或者變更集群。 在組建集群之前，先選出一個節點作為主節點，這裡暫且稱其為主節點，但是其實 PVE 並沒有主從節點概念，集群是通過quorum投票來取得一致性的。確定一個所謂的主節點是因為被加入集群的從節點不能擁有 VM，更底層的原因是 VM id 的全局唯一性約束。所以已經有 VM 的機器是不允許直接加入集群的，需要先備份並銷毀 VM，待進入集群後恢復。 在主節點上創建集群，通過CLUSTER_NAME指定集群名稱： # pvecm create [CLUSTER_NAME] 在從節點上加入集群，CLUSTER-IP-ADDRESS可以是集群中任意一個節點的 IP 地址： # pvecm add [CLUSTER-IP-ADDRESS] 查看集群的狀態： # sudo pvecm status 輸出類似： Cluster information ------------------- Name: Dream Config Version: 8 Transport: knet Secure auth: on Quorum information ------------------ Date: Sun Feb 16 03:32:55 2025 Quorum provider: corosync_votequorum Nodes: 4 Node ID: 0x00000001 Ring ID: 1.b1f Quorate: Yes Votequorum information ---------------------- Expected votes: 4 Highest expected: 4 Total votes: 4 Quorum: 3 Flags: Quorate Membership information ---------------------- Nodeid Votes Name 0x00000001 1 192.168.1.204 (local) 0x00000002 1 192.168.1.201 0x00000003 1 192.168.1.202 0x00000004 1 192.168.1.79 查看集群節點和投票權重： # sudo pvecm nodes 輸出類似： Membership information ---------------------- Nodeid Votes Name 1 1 Enlightenment (local) 2 1 Juan 3 1 Rio 4 1 Rubao 上面兩個命令有正常的返回，說明集群已經組建成功。 順口說一下，如果需要移除一個節點的話，可以用這個命令： # pvecm delnode [NODE-NAME] Ceph 配置 一句話概括 Ceph 是什麼：一種分佈式的網絡存儲，aka 跨節點的高性能高可用的磁盤陣列。下面介紹一下 Ceph 的一些基本概念： Ceph 集群由 Monitor，OSD，MDS，MGR 等服務角色組成； Ceph 通過幾種常見的方式來提供存儲： RBD (Ceph Block Device)：塊設備，提供塊級別的存儲，可以作為虛擬機的磁盤使用； RGW (Ceph Object Gateway)：對象存儲，提供對象級別的存儲，可以作為對象存儲使用，可直接導出為 S3 兼容的對象存儲，NFS 兼容的文件系統等； CephFS (Ceph File System)：POSIX 兼容的文件系統，可以作為文件系統使用。 MON (Monitor) 負責集群的元數據管理，包括集群的拓撲結構，節點的健康狀態等； MGR (Manager) 負責集群的監控和告警，可以通過 Web 界面、API 查看集群的狀態，它還負責支持 Ceph cli 指令，提供 iSCSI Gateway 和 NFS Gateway 等外部訪問服務； OSD (Object Storage Daemon) 負責數據的存儲和檢索，每個節點的每塊物理存儲，都需要配置一個 OSD 進程，他們各自獨立，互不干擾，只對 Monitor 負責； MDS (Metadata Server) 負責文件系統的元數據管理，如果需要使用 CephFS 的話，就需要配置 MDS，CephFS 服務 overhead 較大，根據需要開啟，但作為跨節點文件共享服務相當好用，推薦大家嘗試； PG (Placement Group) 是 Ceph 數據的邏輯管理單元，Ceph 通過 PG 來管理數據分佈，每個 OSD 通常會包含若干個 PG，每個 PG 會根據 CRUSH map 策略在不同 OSD 上放置副本，後面會介紹 PG 的配置策略。 以上提到的角色在 homelab 前提下，都可以放心跑在同一機器上，雖然理想環境是應該分開，但是 homelab 環境下這個妥協不會帶來過多 drawback。 Ceph 是副本冗余，它和 RAID 有一點像，但是並不完全一樣，更接近 Btrfs 的冗餘設計，存儲池的這兩個參數至關重要： Size（副本數）：副本數表示數據的冗餘度，默認是 3，表示數據寫入 3 份，分佈在不同節點（默認）、OSD、機櫃、存儲組或數據中心內，你有多少可寫設備都沒關係，有 5 個節點，如副本數是 3，那麼它依然只把數據放到 3 個節點上； Min Size（最小副本數）：最小副本數表示數據的最小可用冗餘度，默認是 2，表示數據至少需要 2 份副本這份數據才可以被讀寫。 安裝 Ceph 所需要的軟件包 Ceph 配置很簡單，直接在 PVE Web 界面中安裝即可。它會自動安裝 Ceph 並配置成集群，一般無需自己操心。參考這個視頻的前 9 分鐘，可以輕鬆完成。 Ceph 高可用的前提條件 穩定快速的網絡是 Ceph 的基礎，如網絡受限 Ceph 穩定性和性能都會受到很大影響，這就是為什麼建議 10GE 起步； 過得去的 CPU，Ceph 很多操作都要跨節點校對，在超融合框架中 CPU 還要承擔其他業務，所以一定的空閒核心數比較重要，但可放心，現代消費級中高端 CPU 完全能滿足需求，並不需要特別誇張的服務器硬件； 特別注意內存，高性能網絡存儲需要緩存很多索引和數據，特別是元數據映射，至少要為 Monitor 進程預留 4GB 內存，更大的集群可能要 8GB、16GB 甚至更多； 對於存儲節點，根據每個 OSD 所管理的數據大小，理想情況下 1TB 數據需要 1GB 內存以滿足各種訪問請求，若節點上有 10TB SSD 就需要預留 10GB 內存來保障集群效率。 一些常用的 Ceph 命令 檢查 Ceph 健康狀態 # ceph -s cluster: id: 3f0e11a8-f020-45a4-b2ca-dd9fcabc16e2 health: HEALTH_OK services: mon: 3 daemons, quorum Rubao,Rio,Enlightenment (age 10h) mgr: Rio(active, since 3w), standbys: Rubao, Juan, Enlightenment mds: 1/1 daemons up, 3 standby osd: 19 osds: 19 up (since 5h), 19 in (since 6d) data: volumes: 1/1 healthy pools: 4 pools, 145 pgs objects: 1.36M objects, 5.0 TiB usage: 20 TiB used, 45 TiB / 65 TiB avail pgs: 145 active+clean io: client: 1.7 MiB/s rd, 5.1 MiB/s wr, 172 op/s rd, 475 op/s wr 檢查 OSD 狀態 # ceph osd tree ID CLASS WEIGHT TYPE NAME STATUS REWEIGHT PRI-AFF -1 64.58678 root default -9 13.64516 host Enlightenment 13 ssd 0.90970 osd.13 up 1.00000 1.00000 14 ssd 3.63869 osd.14 up 1.00000 1.00000 15 ssd 3.63869 osd.15 up 1.00000 1.00000 16 ssd 3.63869 osd.16 up 1.00000 1.00000 17 ssd 1.81940 osd.17 up 1.00000 1.00000 -7 14.55475 host Juan 2 ssd 3.63869 osd.2 up 1.00000 1.00000 3 ssd 3.63869 osd.3 up 1.00000 1.00000 6 ssd 3.63869 osd.6 up 1.00000 1.00000 7 ssd 3.63869 osd.7 up 1.00000 1.00000 -5 18.19344 host Rio 1 ssd 3.63869 osd.1 up 1.00000 1.00000 5 ssd 3.63869 osd.5 up 1.00000 1.00000 8 ssd 3.63869 osd.8 up 1.00000 1.00000 9 ssd 3.63869 osd.9 up 1.00000 1.00000 10 ssd 3.63869 osd.10 up 1.00000 1.00000 -3 18.19344 host Rubao 0 ssd 3.63869 osd.0 up 1.00000 1.00000 4 ssd 3.63869 osd.4 up 1.00000 1.00000 11 ssd 3.63869 osd.11 up 1.00000 1.00000 12 ssd 3.63869 osd.12 up 1.00000 1.00000 20 ssd 3.63869 osd.20 up 1.00000 1.00000 檢查 Ceph 磁盤空間 # ceph df --- RAW STORAGE --- CLASS SIZE AVAIL USED RAW USED %RAW USED ssd 65 TiB 45 TiB 20 TiB 20 TiB 30.42 TOTAL 65 TiB 45 TiB 20 TiB 20 TiB 30.42 --- POOLS --- POOL ID PGS STORED OBJECTS USED %USED MAX AVAIL .mgr 1 1 73 MiB 16 293 MiB 0 8.0 TiB Ivy 2 64 2.2 TiB 590.48k 8.6 TiB 21.18 8.0 TiB Tea_data 3 64 2.7 TiB 766.34k 11 TiB 25.39 8.0 TiB Tea_metadata 4 16 225 MiB 3.77k 900 MiB 0 8.0 TiB MON 節點個數選擇 Monitor 節點至少需要 3 個，這是因為 Ceph 集群通過 paxos 協議來取得一致性，至少需要 3 個節點確保可用，它具體規則是： vote_threshold = floor(N / 2 + 1) 如果是 2 個節點，那麼 floor(2 / 2 + 1) = 2，也就是說，任何一個節點掛掉，都沒辦法取得一致，集群會卡住，等待故障節點重新上線才會恢復。另外最佳實踐是選擇奇數作為節點數，避免因為腦裂等原因導致重組之後投票失敗，對於家用集群 3 個節點已足夠。5 個節點可以提供多離線一個節點的保障，但所增加的開銷對於 homelab 規模集群可能不划算，因為5個節點會導致網絡上心跳包的開銷更大，對整體硬件的要求會更高。 MDS 節點個數選擇 CephFS 至少需要 1 個 MDS 節點來提供元數據服務來支持 POSIX 兼容的文件系統； MDS 服務器個數選擇不需要考慮一致性投票問題，但要注意在小型集群裡面 Ceph 只會在一個時間內選擇激活一個 MDS 節點，所以更多節點並不會帶來性能提升，但會帶來可用性冗余，因為需要考慮如果 MDS 所在的節點 Down 掉或者需要維護，集群裡面的數據依然可訪問，我在每個節點上都開啟了 MDS，這是一個過度部署的選擇，可以讓我隨便下線節點來維護，比較方便。 Ceph 的空間計算 為什麼reweight很重要，因為它會影響 Ceph 集群的實際可用空間，下面先介紹一下 Ceph 如何計算空間。由於 Ceph 的副本冗餘策略，集群的理論可用空間是通過以下公式計算出來的： total_space = sum(OSD_Capacity) / size 也就是所有 OSD 的容量加起來 / 副本數。對於均勻集群（單個節點磁盤大小一致，每個節點磁盤數也一致），上面的公式等價於： total_space = OSD_Capacity * OSD_num / size 在 PVE Ceph 管理頁面看到的集群容量，就是上面公式計算的理論容量。那麼已經寫入的數據體積，是如何計算的呢？為什麼我只創建了一個 1TB 的 VM，但是卻佔用了幾 TB？這是因為 Ceph 的空間計算是考慮了副本數量，也就是數據體積加總 * 副本數： used_space = sum(data_size) * size 這和 RAID 不一樣，RAID 是組成陣列後減去冗余損耗得到的實際可用容量，RAID 的數據體積是數據的實際體積，不考慮冗余和糾錯。 理論上，集群認為每個節點可寫入容量一致，在默認reweight = 1的情況下，Ceph 寫入時每個節點每個 OSD 都有均等機會來接受寫入，這就是所謂的均勻集群。 OSD 是否需要統一大小的磁盤？ 繼續上面的討論，如果節點不均勻，某些小磁盤會更快寫滿，導致集群過早拒絕寫入。那麼是否一定要構建均勻集群？也不是，這也是大部分科普文章的錯誤所在。事實異構磁盤組成 Ceph 集群，依然高效可靠，但應保持每個節點的磁盤加起來容量相近。否則會造成大容量節點還沒滿，小容量節點報警寫滿，造成空間浪費。對於尺寸不一致的 OSD，可以通過reweight調整權重，這樣可以讓大容量磁盤承擔更多數據，小容量磁盤承擔更少數據，保證每個磁盤的利用率大致均勻，同時最大化集群可用容量。 臨時reweight命令，其中OSD_ID是 OSD 的數字 ID，如osd.1，只需要輸入1即可，REWEIGHT_VALUE是重權值，默認是1，越大表示承擔的數據越多，有效範圍是一個0到1之間的浮點數，注意直接執行reweight命令是一次性的，當磁盤重新上線（in）時reweight值會被重置為1： # ceph osd reweight [OSD_ID] [REWEIGHT_VALUE] 持久化配置要通過以下命令寫入CRUSH map，其中OSD_NAME是 OSD 的完整名字，和上面的OSD_ID不一樣，它包含前面的osd.前綴，如osd.1，REWEIGHT_VALUE的定義和前文保持一致，這裡提到CRUSH map是 Ceph 的核心數據分佈策略，後面會詳細介紹： # ceph osd crush reweight [OSD_NAME] [REWEIGHT_VALUE] 也可以自動根據 osd 利用率來調整reweight，這樣可以保證每個磁盤的利用率大致相同，THRESHOLD是可選閾值，默認120，表示如果磁盤利用率超過集群平均利用率的120%，則進行reweight： Dry run: # ceph osd test-reweight-by-utilization [THRESHOLD] Apply: # ceph osd reweight-by-utilization [THRESHOLD] 還自動根據 PG 數量來調整reweight，這樣可以保證每個磁盤的 PG 數量大致相同，THRESHOLD是可選閾值，默認是120，表示如果磁盤的 PG 數超過集群平均 PG 數量的120%，則進行 reweight： Dry run: # ceph osd test-reweight-by-pg [THRESHOLD] Apply: # ceph osd reweight-by-pg [THRESHOLD] PG 個數選擇 PG 數會影響 Ceph 的性能和數據分佈的均勻程度： 同等數據體積下，PG 數越多，數據越容易均勻分佈，理論上分佈式訪問性能更高，但是過多 PG 會導致元數據過大，影響性能； 反過來如果 PG 數量過小，數據分佈不均勻，會導致某些 OSD 負擔過重，影響集群穩定性。 每個存儲池需要多少個 PG，通常可用以下公式計算： PG_num = (OSD_num * [OSD_TARGET_PG_NUM]) / (pool_num * size) 其中： OSD_num是集群中 OSD 總數； OSD_TARGET_PG_NUM是每個 OSD 的目標 PG 數，廣泛接受的經驗上最佳實踐值是 100； pool_num是存儲池數量； size 是副本數 結果一般會取一個最近的2 的冪作為 PG 數，這樣可以保證將來重新分配時 PG 更容易均勻分佈。 例如我的集群每個節點 5 個 SSD，一共 4 個節點，副本數是 4，有 4 個存儲池，那麼： PG_num = (4 * 5 * 100) / (2 * 4) = 250 ～= 256 (2^8) 偷懶的話也可以直接訪問 PVE Ceph 管理介面，找到Optimal # of PGs，直接寫到對應存儲池 PG 數配置上。 這裡額外說一下幾個常用的配置： PG Auto Scale：自動調整 PG 數量，根據集群負載自動調整 PG 數，建議打開； Target Ratio：目標佔比，指當前存儲池會自動擴展，一直達到佔用整集群空間的目標佔比為止； Target Max PG：最大 PG 尺寸，指當 PG 數據超過此尺寸，將會自動進行重分配到新的 PG 上； Min. # of PGs：這個存儲池最少佔用多少個 PG，默認為 0。 關於 CRUSH map 幾乎所有 Ceph 的重要配置都可以通過修改 CRUSH map 來實現，它控制數據分配策略，你可以在 PVE 的 Ceph 管理介面上看到 CRUSH map 詳情。你可以放心修改 CRUSH map，Ceph 會根據新版本的 CRUSH map 重新平衡數據分佈，整個過程在線完成無需停機，不影響業務，且效率很高。 因此其實你可以隨意往集群裡面添加刪除 OSD，然後修改 CHUSH map 讓數據自動平衡。這是我最喜歡 Ceph 的地方，比任何磁盤陣列都方便，任何磁盤陣列做這類操作都無法做到這麼平滑。 一些常用的 CRUSH map 配置： min_size：最小副本數，默認為 1； 此個設置優先級低於存儲池配置。 max_size：最大副本數，默認為 10； 此個設置優先級低於存儲池配置。 step take default class [CLASS-NAME]：優先選擇何種類型的 OSD，如 hdd，ssd，nvme 等。 對於要按介質分配 OSD 到不同的存儲池，如 SSD 池、HDD 池等非常有用。 介紹一下修改 CRUSH map 的基本步驟： 1. 獲得 CRUSH map 二進制文件 # ceph osd getcrushmap -o crushmap.compiled 2. 解碼 CRUSH map 文件 $ crushtool -d crushmap.compiled -o crushmap.text 3. 修改 CRUSH map 文件 $ vim crushmap.text 4. 編碼 CRUSH map 文件 $ crushtool -c crushmap.text -o crushmap.compiled.new 5. 測試新的 CRUSH map 二進制文件（可選） # crushtool -i crushmap.compiled.new --test --show-X 6. 應用新的 CRUSH map 二進制文件 # ceph osd setcrushmap -i crushmap.compiled.new 邁向高可用 所謂小集群服務的高可用，除了網絡本身要有冗余，電源方案要有 UPS 和發電機之外（是的，我有發電機），VM 能自動從故障的物理節點中遷移和重建很重要。PVE 集群可以通過HA (High Availability)面板來配置，前提是上面提到的 PVE 集群、Ceph集群都已正確配置。 找到HA管理頁面，創建lrm節點； 可以在所有的節點上開啟 lrm 服務。 創建HA Group，如果 VM 對硬件沒有特別需求，可忽略這一步； 如果你的業務需要不同的資源組合，例如你有兩個大內存的節點，兩個小內存的節點，你應該把大小內存的節點劃分為兩個資源組，這樣可以保證對內存依賴高的 VM 能遷移到適合的節點上，類似地也需要把有顯卡的機器編成一個組，但是顯卡比較特殊，後面我會再補充。 在HA Resource面板添加需要作為高可用服務的 VM。 選擇 VM 和對應的HA Group（如需要），配置Max. Restart（最大的自動重啟次數）和Max. Relocate（最大遷移次數），按添加即可。 測試，配置成功之後，在 VM 所在的節點上拔出網線，VM 應該會自動遷移到其他機器上運行，如出錯，可查看cluster log進行排查。 關於顯卡以及其他有直通硬件依賴的高可用配置 有一些業務依賴 GPU 或者其他硬件，這些 VM 在自動遷移之後，需要找到功能可替代的硬件才能正常運行。這一類的 VM 需要一些額外的配置步驟來實現高可用： 在 PVE 配置頁面上找到Resource Mappings創建一個 PCI / USB 資源組，如 GPU 組，然後把某一個節點上的 GPU 加入這個 PCI 資源組； 在資源組 Actions 列中找到+加號，添加其他節點上的兼容資源，通常為另一個節點上的 GPU； 修改 VM 配置，刪除基於 PCI 地址的硬件，重新添加上面綁定的映射硬件； 創建一個和Resource Mappings對應的HA Group； 在HA Resource面板，添加需要高可用的 VM 和對應的資源組。 這樣配置之後，VM 在遷移的時候，會自動遷移到有相應硬件資源的節點上。 備份方案 PBS（Proxmox Backup Server）是 PVE 的衍生項目，是針對 PVE 設計的原生備份方案。它很容易整合到 PVE 集群上，作為備份服務的延伸，提供從容器到 VM，甚至物理主機的完整備份方案。 安裝 PBS 有多種方法安裝 PBS，可以直接從官網下載啟動鏡像，DD 到 U 盤上，直接安裝成一個獨立的備份服務器。也可在 Debian / PVE 上安裝，以下詳細說一下這種方式，也是我所使用的安裝方式。注意 PVE 和 PBS 可以獨立安裝也可以和諧共存到一個主機上，當然有條件的話，還是推薦獨立一個備份服務器，但基於資源利用的考慮，我選擇了把 PBS 安裝到一個存儲資源富裕的 PVE 節點上。 1. 獲得 PBS APT 源的密鑰： # wget https://enterprise.proxmox.com/debian/proxmox-release-bookworm.gpg -O /etc/apt/trusted.gpg.d/proxmox-release-bookworm.gpg 2. 驗證密鑰： $ sha512sum /etc/apt/trusted.gpg.d/proxmox-release-bookworm.gpg 7da6fe34168adc6e479327ba517796d4702fa2f8b4f0a9833f5ea6e6b48f6507a6da403a274fe201595edc86a84463d50383d07f64bdde2e3658108db7d6dc87 /etc/apt/trusted.gpg.d/proxmox-release-bookworm.gpg 3. 添加 APT 源： # vim /etc/apt/sources.list.d/pbs.list 對於付費用戶： deb https://enterprise.proxmox.com/debian/pbs bookworm pbs-enterprise 對於免費用戶： deb http://download.proxmox.com/debian/pbs bookworm pbs-no-subscription 對於不怕死的嚐鮮用戶： deb http://download.proxmox.com/debian/pbs bookworm pbstest 對於只需要備份客戶端，不需要備份服務器的用戶： # for Debian Bookworm deb http://download.proxmox.com/debian/pbs-client bookworm main # for Debian Bullseye deb http://download.proxmox.com/debian/pbs-client bullseye main # for Debian Buster / Ubuntu 20.04 LTS deb http://download.proxmox.com/debian/pbs-client buster main 4. 安裝 PBS 服務器 # apt update # apt install proxmox-backup-server 5. 安裝 PBS 客戶端 # apt update apt install proxmox-backup-client 未完待續 抱歉，我的 PBS 服務最近在做存儲升級，陣列文件系統在升級中，等服務器升級完成，我會繼續補充這部分內容。

I’ve had the UNAS for a few weeks, and before receiving it, I was concerned about the lack of RAID 5 support on the UNAS Pro. However, RAID 6 protection is crucial for my stored data. As a long-time mdadm user, and knowing that UNAS also utilizes it, I was confident in my ability to resolve this issue independently. Given mdadm’s robust support for array modification and migration, I believed that directly expanding the array using the grow command would address the problem. You can start with any RAID configuration because mdadm allows for lossless migration from RAID 0, RAID 1, and RAID 5 to RAID 6. Specific migration constraints exist, but a simple calculation can provide a rough verification, though you should always consider your array’s specific situation. Generally, migration is feasible if the resulting array’s usable capacity is equal to or greater than the current usable capacity. If the migration results in reduced disk capacity, such as when upgrading from RAID 5 to RAID 6 without adding disks or utilizing a hot spare disk, you’ll need to shrink the storage partition beforehand. This involves moving data to the front of the disk and trimming the unused space, which can be achieved using resize2fs. However, this is beyond the scope of this discussion. Most UNAS users likely have RAID 5 configured. If a hot spare disk was previously designated, upgrading to RAID 6 using that hot spare is the simplest, quickest, and safest method. This process is also straightforward if an empty drive bay is available on your UNAS. However, if no spare disks or bays are available, reducing partition size and removing a disk before migrating will be required. For example, I previously used RAID 5 with all disks utilized. I had reduced the partition volume and added a hot spare disk. I then executed the following command to upgrade: mdadm –grow /dev/md3 –level=6 –raid-devices=7 Please note that the upgrade is required for md3. md0 is reserved for other system metadata storage. You can use the command watch cat /proc/mdstat in the terminal to monitor the disk synchronization progress. Once synchronization is complete, you will see the following information. root@UNAS-Pro:~# cat /proc/mdstat Personalities : [linear] [raid0] [raid1] [raid6] [raid5] [raid4] [raid10] md0 : active raid1 sdg2[0] sdb2[6] sda2[5] sdd2[4] sdf2[3] sdc2[2] sde2[1] 1961984 blocks super 1.2 [7/7] [UUUUUUU] md3 : active raid6 sdg5[0] sdb5[6] sda5[5] sdd5[4] sdf5[3] sdc5[2] sde5[1] 58551802880 blocks super 1.2 level 6, 512k chunk, algorithm 2 [7/7] [UUUUUUU] bitmap: 0/6 pages [0KB], 65536KB chunk unused devices: <none> Executing mdadm –detail /dev/md3 will now show that the array has been completely converted to RAID6. root@UNAS-Pro:~# mdadm –detail /dev/md3 /dev/md3: Version : 1.2 Creation Time : Thu Jan 16 11:33:12 2025 Raid Level : raid6 Array Size : 58551802880 (55839.35 GiB 59957.05 GB) Used Dev Size : 11710360576 (11167.87 GiB 11991.41 GB) Raid Devices : 7 Total Devices : 7 Persistence : Superblock is persistent Intent Bitmap : Internal Update Time : Wed Jan 22 10:30:20 2025 State : clean Active Devices : 7 Working Devices : 7 Failed Devices : 0 Spare Devices : 0 Layout : left-symmetric Chunk Size : 512K Consistency Policy : bitmap Name : UNAS-Pro:3 (local to host UNAS-Pro) UUID : e3bde202:cbb13026:be46c779:add176fb Events : 125218 Number Major Minor RaidDevice State 0 8 101 0 active sync /dev/sdg5 1 8 69 1 active sync /dev/sde5 2 8 37 2 active sync /dev/sdc5 3 8 85 3 active sync /dev/sdf5 4 8 53 4 active sync /dev/sdd5 5 8 5 5 active sync /dev/sda5 6 8 21 6 active sync /dev/sdb5 Upgrading from version 5 to 6 is generally safe, but please ensure you back up your data beforehand. After waiting approximately a day for the disk to synchronize, all services were running normally and the data remained intact. At this point, the management interface will still display “Basic Protection” because the UI reflects a configuration file. To proceed, access the UniFi OS terminal and edit the file at /data/unifi-core/config/settings.yaml. root@UNAS-Pro:~# cat /data/unifi-core/config/settings.yaml anonymous_device_id: xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx isInternalUser: false isSetup: true location: lat: xx.111966 long: -xxx.0323814 radius: 200 text: Uranium City, Saskatchewan, Canada name: UNAS Pro timezone: America/Toronto sendDiagnostics: anonymous autoBackupEnabled: true internetRequired: true lcmSettings: enabled: true color: 0139FF brightness: 100 ledSettings: enabled: true nightMode: onMinute: 180 offMinute: 181 owner: null emailServiceProvider: ui ustorage: hotspare: false raid: raid6 setup_device_id: xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx setupType: ios setupDuration: null country: 124 ssh: agreementAcceptedAt: 2025-01-10T19:56:13.116Z agreementAcceptedByUserId: xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx The configuration needs to be updated to match the changes made to the mdadm array during migration. For example, I changed the hotspare setting from true to false, and the RAID level from RAID5 to RAID6. You will see these changes reflected in the configuration on the management webpage. If the changes are not updated, reboot the server to see the correct information. You can now enjoy using RAID 6 on your UNAS Pro. Actually, there are two ways to access the configuration page on UNAS Pro. One method is through UniFi’s cloud access; however, the “Advanced Protection” setting will not be visible because the UI for UniFi OS 4.1.11 / Drive 1.16.15 is not yet adapted. You can see the correct configuration by accessing via local IP address. This explains why some community members can see this configuration, while others cannot. This issue is expected to be resolved in OS 4.2, but it does not impact functionality. Additionally, if you are using a 10G connection on your local network, remember to enable jumbo frames for optimal performance. The simplest way to do this is by adding the following to /etc/crontab: @reboot root /sbin/ip link set enp0s2 mtu 9000 My local network can essentially run at the full 10Gbps speed. root@UNAS-Pro:~# iperf3 -c 192.168.1.204 Connecting to host 192.168.1.204, port 5201 [ 5] local 192.168.1.64 port 60334 connected to 192.168.1.204 port 5201 [ ID] Interval Transfer Bitrate Retr Cwnd [ 5] 0.00-1.00 sec 1.09 GBytes 9.34 Gbits/sec 497 760 KBytes [ 5] 1.00-2.00 sec 1.11 GBytes 9.55 Gbits/sec 804 516 KBytes [ 5] 2.00-3.00 sec 1.09 GBytes 9.40 Gbits/sec 825 341 KBytes [ 5] 3.00-4.00 sec 1.12 GBytes 9.61 Gbits/sec 1030 533 KBytes [ 5] 4.00-5.00 sec 1.10 GBytes 9.49 Gbits/sec 741 428 KBytes [ 5] 5.00-6.00 sec 1.10 GBytes 9.43 Gbits/sec 911 376 KBytes [ 5] 6.00-7.00 sec 1.13 GBytes 9.70 Gbits/sec 789 1.13 MBytes [ 5] 7.00-8.00 sec 1.08 GBytes 9.27 Gbits/sec 790 341 KBytes [ 5] 8.00-9.00 sec 1.10 GBytes 9.49 Gbits/sec 483 568 KBytes [ 5] 9.00-10.00 sec 1.12 GBytes 9.66 Gbits/sec 733 306 KBytes [ ID] Interval Transfer Bitrate Retr [ 5] 0.00-10.00 sec 11.1 GBytes 9.49 Gbits/sec 7603 sender [ 5] 0.00-10.00 sec 11.0 GBytes 9.49 Gbits/sec receiver Okay, that concludes this discussion. Please feel free to leave comments if you have any questions. As a final reminder, always back up your important data before making any array changes. PS: This article was originally published in the UniFi community by me, and the original link can be found here: https://community.ui.com/questions/Enable-RAID-6-on-UNAS-Pro-without-waiting/8b333b9f-5168-4261-b81a-1eab3c039de7 .

// Created by @leaskh with DALL-E. I helped my friend write an AI system for processing documents. One part of it is to process the original document as the basis for the next prompt. Previously, we used Google OCR after comparing many OCR tools. I spent some time over the weekend changing it to preprocess through OpenCV and then extracting information using multimodal AI. Ah! It’s so much better than traditional tool chains. The results are tearfully good. The following two images show a comparison of processing the same IELTS score report (sample). OCR vs Multimodal AI: After AI transformation, it can produce relatively controllable outputs through prompt engineering. For example, whether to keep the original text or simplify it, remove unnecessary information such as headers, footers, watermarks, etc., and purposefully simplify and abstract based on context. It can also modify errors and writing in the original text. If traditional OCR is used, due to the mechanical nature of the scanning process, even applying an LLM makes it difficult to correct data relationships that have already been lost previously, such as complex tables and charts in a scene. The transformation of software development by AI not only involves the user interface that users directly interact with, but also has many possibilities for innovative toolchain-level improvements. These optimizations can greatly enhance the usability of productivity tools, reduce the workload for users to process information in later stages, and alleviate the fatigue of controlling precision in repetitive work. I think this applies equally to language models (LLM) and image models. More subtle improvements will be widespread. In the visible future, even if it is not a software aimed at AI, benefiting from the introduction of large-scale system-level AI small models, runtime-level integration will make this kind of optimization simpler and all software will become smarter than they are now. This point is completely foreseeable and has already happened on the way.

// Created by Leask with Dall-E Objectively speaking, Apple’s AI strategy this time is not optimistic. The apparent contradiction is that Apple is unwilling to relinquish the Siri brand. On the one hand, the privacy story cannot be completed, and at the same time, Siri and Apple’s accumulation in their own AI models is still far behind. But they also need to catch up with the Gen AI wave, so they made a very temporary design to allow GPT to be asked again when Siri doesn’t understand it. Everyone can see from today’s WWDC Keynote that even after the upgrade, Siri is still only able to answer very basic questions. Other tasks, such as photo categorization and email and message sorting, can be completed by small models at the classifier level. The first-party Gen AI truly only has Image Playground and Rewrite Text. This is still far from true deep integration like Copilot. I do not deny that Apple can be very efficient and delicate in engineering integration. The problem is that such superficial integration cannot truly unleash the full potential of the current LLM model. It still may be pretty clumsy to use. However, embedding data may not be accessible to developers due to privacy or competitive considerations, so the ultimate experience could be limited to what was shown in today’s demo, possibly smaller than everyone had imagined. Compared to Microsoft’s current strategy, Microsoft cut off Cortana a few years ago, which was intentional. They saw the limitations of traditional models and the potential for explosive growth in AI generation, so they made a bold move. Copilot now has many operations that can be done in one step, and its runtime is very complete and open, allowing for calls from multiple perspectives. This is what an “All in” posture should look like. Microsoft also uses ChatGPT, but it is not secretive about it. It customizes on top of ChatGPT, from integrating Bing results to introducing Dall-E and adding Recall-enhanced Embedding, etc. In fact, all of these are centred around ChatGPT. It can adapt better than ChatGPT and still provide rich local data. Apple’s integrated ChatGPT is still like a plugin and is limited by a flawed Siri foundation.
